AiecoPower 6W 5V 1.2A 12V 0.5A 0.6A UK Plug AC DC Wall Power Adaptor

The SAW06C series 6W AC DC Wall Power Adaptor is specifically engineered with a UK Plug, providing efficient and stable power tailored for the UK market.

This globally certified adapter meets stringent energy requirements, including the critical DoE Level VI efficiency standards. Comprehensive safety is guaranteed with Over-Current Protection (OCP), Over-Voltage Protection (OVP), and Short-Circuit Protection (SCP).

Built using premium-quality electron components and strict production processes, the SAW06C ensures exceptional long-term stability and a safe charging experience. It is the ideal UK wall plug adapter for small electronic devices such as IoT hubs, IP cameras, and network peripherals.

Categorías: ,

Specification



  • Model Number: SAW06C-xxx-yyyyDK
  • Environmental Standards: Fully RoHS and REACH compliant for global market access.
  • Quality Assurance: Reliability ensured through Drop-In Tested and 100% Burn-In Tested procedures.
  • Major Global Certifications: Holds essential safety approvals including cUL, FCC, CE, UKCA and more.
  • Ultra-Compact Size: Space-saving dimensions of 45.5 x 40.9 x 22.9mm.
  • Color Availability: Available in standard Black and White casing options.

Specification Details

Power Supply ModelSAW06C
input voltage&Frequency100-240VAC, 50/60Hz, 0.3A
Output Powermax. 6W
Full Load EfficiencyDOE VI,ERP VI etc
Burn-in Test80% to 100% load, 40 C°± 5℃ for 4 hours
Hi-Pot TestPrimary To Secondary: 3000VAC 10mA 1 minute or 4000VDC 10mA 3 Sec.
Operating temperature0 to 40℃
Length of DC cordOptional (1.2m 1.5m 1.83m etc)
DC plugOptional (5.5x2.5mm 5.5x2.5mm 3.5x1.35mm etc)
Product Dimensions (mm)43.5x41x23.5
Ripple & Noise120Vp-p Max
PackageWhite box or Plastic Bag with outer carton
No load Power Consumption< 0.075W
Protection functionShort-circuit/OVP/OCP etc
Safety CertificateEN62368:UL/CB/CE/GS/EMC/LVD/RCM/KC/FCC/PSE/CCC
EN61558:CE/GS/CB/FCC/LVD/RCM UL 1310
Warranty3 years

Drawing:



Typical Output

I/P Voltage Typical ModelOutput VoltageOutput CurrentRipple& NosieEffiviency Level
100-240V/50-60HzSAW06C-050-10005V1000mA100mVVI
SAW06C-050-12005V1200mA100mVVI
SAW06C-059-10005.9V1000mA100mVVI
SAW06C-120-050012V500mA100mVVI
SAW06C-120-060012V600mA100mVVI
